Corona Pendant Transparent

Corona Pendant Transparent

CRL Series | Direct & Indirect Architectural LED
Contact for Pricing
FEATURES SPECIFICATIONS
Corona Pendant Transparent is a commercial pendant lighting fixture utilizing an advanced LED optical system to achieve superior performance. The unique design is nearly transparent luminaire when off and excellent uniformity and efficiency when on, reaching 55% downlighting and 45% uplighting distribution, making the illusion of the light floating in mid-air. It has CCT adjustable optional function which is available in 3000K,3500K and 4000K. It’s highly engineered luminaire joining design allows for simple and intuitive assembly in the field without tools which is perfect for applications that include conference rooms, open offices, retail settings, anywhere you want to make a statement.
  • Transparent horizontal optics appear like a floating dormer
  • Extruded aluminum construction in 4', 6' & 8' modules.
  • Direct/indirect general area lighting distributions
  • 0-10V dimming, dim to 10% or 1% options
  • Internal & replaceable driver
  • CCT adjustable from 3000K, 3500K, 4000K
  • Continuous runs up to 40ft in 120VAC
  • UL, cUL listed, DLC qualification, Damp Rated, 5 years limited warranty
Size8inch width
Light SourceLED Static
LumensUp To 9600LM
CCT3000K, 3500K, 4000K
CRI80, 90
ListingUL, cUL, DLC, Damp Rated
Dimming Protocol0-10V
Reflector StylePMMA LGP
FinishBlack, White
Mounting TypePendant
Voltage Rating110-277VAC
Fixture Length4ft, 6ft, 8ft Standard
Installation INSTALLATION INSTRUCTION
Download not available.
