Corona Pendant Transparent
CRL Series | Direct & Indirect Architectural LED
Contact for Pricing
FEATURES
SPECIFICATIONS
Corona Pendant Transparent is a commercial pendant lighting fixture utilizing an
advanced LED optical system to achieve superior performance. The unique
design is nearly transparent luminaire when off and excellent uniformity
and efficiency when on, reaching 55% downlighting and 45% uplighting
distribution, making the illusion of the light floating in mid-air. It has CCT
adjustable optional function which is available in 3000K,3500K and 4000K.
It’s highly engineered luminaire joining design allows for simple and
intuitive assembly in the field without tools which is perfect for applications
that include conference rooms, open offices, retail settings, anywhere you
want to make a statement.
- Transparent horizontal optics appear like a floating dormer
- Extruded aluminum construction in 4', 6' & 8' modules.
- Direct/indirect general area lighting distributions
- 0-10V dimming, dim to 10% or 1% options
- Internal & replaceable driver
- CCT adjustable from 3000K, 3500K, 4000K
- Continuous runs up to 40ft in 120VAC
- UL, cUL listed, DLC qualification, Damp Rated, 5 years limited warranty
| Size | 8inch width |
|---|---|
| Light Source | LED Static |
| Lumens | Up To 9600LM |
| CCT | 3000K, 3500K, 4000K |
| CRI | 80, 90 |
| Listing | UL, cUL, DLC, Damp Rated |
| Dimming Protocol | 0-10V |
| Reflector Style | PMMA LGP |
| Finish | Black, White |
| Mounting Type | Pendant |
| Voltage Rating | 110-277VAC |
| Fixture Length | 4ft, 6ft, 8ft Standard |
